Cytology Brushes

Description

ENDO-FLEX - cytology brushes for endoscopic removal of cell smears. The metal head at the end of the brush locks the sample when withdrawn and prevents sample loss or contamination.

  • 1 and 2 lumen designs:
  • 2-lumen version for use with guide wire for working channels from 3.2 mm Ø
  • 1-lumen version with a metal head acting as a closure for working channels from 2.0 mm Ø
  • lengths: between 120 cm and 230 cm
  • brush with a conical, atraumatic tip

Product Images and Videos

Customer Service
Any Questions about the product? +49 8032 973-0 sales (at) medi-globe.de

More Information

Cytology Brush – Single Lumen

Catalogue No. Working Length (cm) Sheath Outer Diameter (mm) Min. Accessory Channel (mm)
E4218-A 120 1.8 2.0
E4218-C 180 1.8 2.0
E4219-G 230 1.9 2.2
E4222-G 230 2.3 2.8



Cytology Brush – Single Lumen

Catalogue No. Working Length (cm) Sheath Outer Diameter (mm) Min. Accessory Channel (mm)
NE4218-A 120 1.8 2.0
NE4218-C 180 1.8 2.0
NE4222-G 230 2.3 2.8



Cytology Brush – Double Lumen

Compatible with guide wire .035”

Catalogue No. Working Length (cm) Sheath Outer Diameter (mm) Min. Accessory Channel (mm)
E4222DL-C 180 2.7 3.2

Instructions for Use - Cytology Brushes SU

File size: 989 KB
Type: PDF

Leaflet Cytology Brushes - Single Use

File size: 282 KB
Type: PDF
