Guide Wires

Description

ENDO-FLEX guide wires are made of Nitinol and are equipped with a flexible to highly flexible plastic tip (straight or curved) and a colored plastic coating (violet-white and violet-yellow).

  • convenient sliding properties
  • hydrophilic coating
  • diameter .025" and .035"
  • available lengths: between 300 cm and 600 cm.

Product Images and Videos

Customer Service
Any Questions about the product? +49 8032 973-0 sales (at) medi-globe.de

More Information

5 cm hydrophilic tip

Catalogue No. Description Diameter (inch/mm) Length (cm) Flexible Part (cm) Colour
21725450 High Flexible Straight Tip .025 / 0.64 450 5 Violet / Yellow
21735450 High Flexible Straight Tip .035 / 0.89 450 5 Violet / Yellow
21735600 High Flexible Straight Tip .035 / 0.89 600 5 Violet / Yellow
Catalogue No. Description Diameter (inch/mm) Length (cm) Flexible Part (cm) Colour
21825450 High Flexible Curved Tip .025 / 0.64 450 5 Violet / Yellow
21835450 High Flexible Curved Tip .035 / 0.89 450 5 Violet / White

50 cm hydrophilic coating

Catalogue No. Description Diameter (inch/mm) Length (cm) Flexible Part (cm) Colour
21635450 Flexible Standard Tip .035 / 0.89 450 5 Violet / White

Teflon-coated

Catalogue No. Description Diameter (inch/mm) Length (cm) Flexible Part (cm) Colour
21025400 Flexible Tip .025 / 0.64 400 30 Green
21535400 Flexible Tip .035 / 0.89 300 30 Green
21035400 Flexible Tip .035 / 0.89 400 30 Green
21052400 Flexible Tip .052 / 1.32 400 30 Green

Instructions for Use - Nitinol Guide Wires hydrophilic coated Nitinol Guide Wires SU “Smart-Guide” and “Hi-Flex”

File size: 1,008 KB
Type: PDF

Instructions for Use - Stainless Steel Guide Wires SU - Teflon coated

File size: 1,003 KB
Type: PDF
