Multi-Stage Dilation Balloons

Description

The multi-stage dilation balloons have a clear, transparent plastic balloon, which offers a uniform diameter with maximum radial force. Each balloon can gradually reach three different diameters.

Both variants can be easily positioned through the endoscope using a guide wire. X-ray markings supported the exact placement.

Easy placement through the endoscope (TTS)

  • compatible with .035" guide wires
  • balloon diameters from 6 mm to 15 mm (biliary) and 6 mm to 20 mm for esophageal variants

Product Images and Videos

Customer Service
Any Questions about the product? +49 8032 973-0 sales (at) medi-globe.de

More Information

Esophageal Dilation Balloon

Pre-loaded hydrophilic guide wire .035“, with radiopaque markers, 3 progressive stages, total length 230 cm

Catalogue No. Balloon Diameter (mm) Balloon Length (mm) Catheter Outer Diameter (French) Max. Pressure (psi/atm) Min. Accessory Channel (mm)
34106PRO 6–7–8 55 7 145/10 2.8
34108PRO 8–9–10 55 7 130/9 2.8
34110PRO 10–11–12 55 7 115/8 2.8
34112PRO 12–13.5–15 55 7 115/8 2.8
34115PRO 15–16.5–18 55 7 100/7 2.8
34118PRO 18–19–20 55 7 145/10 2.8



Biliary Dilation Balloon

Pre-loaded hydrophilic guide wire .035”, with radiopaque markers, 3 progressive stages, total length 200 cm

Catalogue No. Balloon Diameter (mm) Balloon Length (mm) Catheter Outer Diameter (French) Max. Pressure (psi/atm) Min. Accessory Channel (mm)
3410630PRO 6–7–8 30 7 145/10 2.8
3410830PRO 8–9–10 30 7 130/9 2.8
3411030PRO 10–11–12 30 7 115/8 2.8
3411230PRO 12–13.5–15 30 7 115/8 2.8

Instructions for Use - Progressive Dilation Balloons SU

File size: 1,005 KB
Type: PDF

Leaflet Multi-Stage Dilation Balloons - Single Use

File size: 211 KB
Type: PDF
