Polypectomy Snares - Special Shapes

Description

ENDO-FLEX special shapes of polyectomy snares - hexagonal and asymmetrical snare shapes in different snare sizes with monofilament or multifilament wires. They allow the removal of smaller and larger lesions in positions that cannot be reached with standard snares.

  • hexagonal
  • asymmetric

Product Images and Videos

Customer Service
Any Questions about the product? +49 8032 973-0 sales (at) medi-globe.de

More Information

Oval loop, braided wire

Catalogue No. Loop Shape Loop Diameter (mm) Sheath Diameter (mm) Min. Accessory Channel (mm) Working Length (cm)
OE342215-G Oval 20 2.3 2.8 230
OE342216-G Oval 25 2.3 2.8 230
OE342217-C Oval 35 2.3 2.8 180
OE342217-G Oval 35 2.3 2.8 230



Oval loop, monofilament wire

Catalogue No. Loop Shape Loop Diameter (mm) Sheath Diameter (mm) Min. Accessory Channel (mm) Working Length (cm)
OE342214M-G Oval 15 2.3 2.8 230



Asymmetrical loop, braided wire

Catalogue No. Loop Shape Loop Diameter (mm) Sheath Diameter (mm) Min. Accessory Channel (mm) Working Length (cm)
OE3322-G Asymmetrical 25 2.3 2.8 230

Oval loop, braided wire, rotatable

Catalogue No. Loop Shape Loop Diameter (mm) Sheath Diameter (mm) Min. Accessory Channel (mm) Working Length (cm)
NOE341816-C Oval 25 1.8 2.0 180
NOE342213-G Oval 10 2.35 2.8 230
NOE342214-C Oval 15 2.35 2.8 180
NOE342214-G Oval 15 2.35 2.8 230
NOE342214-M Oval 15 2.35 2.8 280
NOE342216-C Oval 25 2.35 2.8 180
NOE342216-G Oval 25 2.35 2.8 230
NOE342217-C Oval 35 2.35 2.8 180
NOE342217-G Oval 35 2.35 2.8 230
NOE342217-M Oval 35 2.35 2.8 280



Oval loop, monofilament wire, rotatable

Catalogue No. Loop Shape Loop Diameter (mm) Sheath Diameter (mm) Min. Accessory Channel (mm) Working Length (cm)
NOE342212M-G Oval 6 2.35 2.8 230
NOE342213M-G Oval 10 2.35 2.8 230
NOE342214M-C Oval 15 2.35 2.8 180
NOE342214M-G Oval 15 2.35 2.8 230
NOE342216M-C Oval 25 2.35 2.8 180
NOE342216M-G Oval 25 2.35 2.8 230
NOE342217M-G Oval 35 2.35 2.8 230



Hexagonal loop, braided wire, rotatable

Catalogue No. Loop Shape Loop Diameter (mm) Sheath Diameter (mm) Min. Accessory Channel (mm) Working Length (cm)
NOE372214-G Hexagonal 15 2.35 2.8 230
NOE372216-G Hexagonal 25 2.35 2.8 230
NOE372217-G Hexagonal 35 2.35 2.8 230



Asymmetrical loop, braided wire, rotatable

Catalogue No. Loop Shape Loop Diameter (mm) Sheath Diameter (mm) Min. Accessory Channel (mm) Working Length (cm)
NOE3222-G Asymmetrical 15 2.35 2.8 230
NOE3322-G Asymmetrical 25 2.35 2.8 230

Leaflet Polypectomy / Mucosectomy Snares - Single Use

File size: 216 KB
Type: PDF
