Sphincterotomes

Description

ENDO-FLEX sphincterotomes are equipped with different tip shapes and ring markings on the tube for precise positioning. In addition to 1-lumen, also 2- and 3-lumen versions are available. Depending on the type of sphincterotome, it can be placed with a guide wire and/or contrast agent can be injected through a side opening. The ENDO-FLEX portfolio includes several variants for different forms of application, which are designed for use with high-frequency electricity.

  • different tip shapes and ring markings
  • single and multiple lumen variants
  • suitable for guide wire (most versions)
  • special sphincterotomes ( e.g. B-II and needle types)
  • variants with side cutting wire for precise cutting
  • types with semi-insulated cutting wire for safe and controlled papillary roof incision
  • needle and knife sphincterotomes for a frontal papillary cut
  • application B-II sphincterotomes

Product Images and Videos

Customer Service
Any Questions about the product? +49 8032 973-0 sales (at) medi-globe.de

More Information

Sphincterotome without Guide Wire Access

Length 200 cm; colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1031821 Pre-Cut-Type - 20 1.8 2.2
OE1031831 Pre-Cut-Type - 30 1.8 2.2
OE1051821 Tapered Tip, Strengthened 5 20 1.8 2.2
OE1051830 Tapered Tip, Strengthened 5 30 1.8 2.2
OE1051831 Tapered Tip, Strengthened 5 30 1.8 2.2
OE1051815PC Pre-Cut-Type with Tapered Tip, Strengthened - 15 1.8 2.2
OE1051821PC Pre-Cut-Type with Tapered Tip, Strengthened - 20 1.8 2.2
OE1051831PC Pre-Cut-Type with Tapered Tip, Strengthened - 30 1.8 2.2



Sphincterotome compatible with Guide Wire .035”

Length 200 cm; colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1031830GW Pre-Cut-Type - 30 1.8 2.2
OE1031831 Pre-Cut-Type - 30 2.45 / 1.85 2.8
OE1051820GW Tapered Tip 5 20 2.45 / 1.85 2.8
OE1051830GW Tapered Tip 5 30 2.45 / 1.85 2.8
OE1051825GW11M Tapered Tip, Monofilament Cutting Wire, Cutting Direction 11 o‘clock 5 25 2.45/1.85 2.8



B-II-Sphincterotome compatible with Guide Wire .035”

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE11222FD B-II-Type 15 200 2.8 3.0
OE11222FD-280* B-II-Type 15 280 2.8 3.0



Needle Knife Sphincterotome without Guide Wire Access

Colored ring markers

Catalogue No. Needle Projection Needle Stopp at (mm) Length (cm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE11018N3 Pointed Type 3 200 1.8 2.0
OE11018N6 Pointed Type 6 200 1.8 2.0
OE11018N3-280 Pointed Type 3 280 1.8 2.0
OE11018SP3 Blunt Type 3 200 1.8 2.0
OE11018SP6 Blunt Type 6 200 1.8 2.0



Sphincterotome compatible with Guide Wire .035”

Colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Length (cm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1002220DL Standard Tip 5 20 200 2.55/2.1 2.8
OE1002225DL Standard Tip 5 25 200 2.55/2.1 2.8
OE1002230DL Standard Tip 5 30 200 2.55/2.1 2.8
OE1022220DL Pre-Cut-Type - 20 200 2.55/2.1 2.8
OE1022225DL Pre-Cut-Type - 25 200 2.55/2.1 2.8
OE1022230DL Pre-Cut-Type - 30 200 2.55/2.1 2.8



Sphincterotome “Smart Tip” compatible with Guide Wire .035”

Colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Length (cm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1042220DL Tapered Tip 5 20 200 2.55/2.1 2.8
OE1042225DL Tapered Tip 5 25 200 2.55/2.1 2.8
OE1042230DL Tapered Tip 5 30 200 2.55/2.1 2.8
OE1042220DL-2 Tapered Tip 2 20 200 2.55/2.1 2.8
OE1042230DL-280* Tapered Tip 5 30 280 2.55/2.1 2.8



Preloaded Guide Wire Sphincterotome incl. HI-FLEX-Wire 21735450

Colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Length (cm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1042225DL-SET01 Smart Tip 5 25 200 2.55/2.1 2.8
OE1042230DL-SET01 Smart Tip 5 30 200 2.55/2.1 2.8



Sphincterotome “Smart Cut” compatible with Guide Wire .035”

Colored ring markers; partially insulated cutting wire

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Length (cm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1042220DLC Smart Tip 5 20/10 200 2.55/2.1 2.8
OE1042225DLC Smart Tip 5 25/12 200 2.55/2.1 2.8
OE1042230DLC Smart Tip 5 30/15 200 2.55/2.1 2.8
OE1042230DLC1 Tapered Tip 10 30/15 200 2.55/2.1 2.8



Needle Knife Sphincterotome compatible with Guide Wire .035”

Colored ring markers

Catalogue No. Needle Projection Needle Stopp at (mm) Length (cm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE11018N-DL Pointed Type 6 200 2.55/2.1 2.8
OE11018N3-DL Pointed Type 3 200 2.55/2.1 2.8

Sphincterotome compatible with Guide Wire .035”

Length 200 cm; colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1002220TRL Standard Tip 5 20 2.55/2.1 2.8
OE1002225TRL Standard Tip 5 25 2.55/2.1 2.8
OE1002230TRL Standard Tip 5 30 2.55/2.1 2.8
OE1022220TRL Pre-Cut-Type - 20 2.55/2.1 2.8
OE1022225TRL Pre-Cut-Type - 25 2.55/2.1 2.8
OE1022230TRL Pre-Cut-Type - 30 2.55/2.1 2.8
OE1002220TRL-M Standard Tip, Monofilament Cutting Wire 5 20 2.55/2.1 2.8
OE1002225TRL-M Standard Tip, Monofilament Cutting Wire 5 25 2.55/2.1 2.8
OE1002230TRL-M Standard Tip, Monofilament Cutting Wire 5 30 2.55/2.1 2.8



Sphincterotome “Tapered Tip” compatible with Guide Wire .035”

Length 200 cm; colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1042220TRL Tapered Tip 5 20 2.55/2.1 2.8
OE1042225TRL Tapered Tip 5 25 2.55/2.1 2.8
OE1042230TRL Tapered Tip 5 30 2.55/2.1 2.8
OE1042220TRL-3 Tapered Tip 3 20 2.55/2.1 2.8
OE1042220TRL-M Tapered Tip, Monofilament Cutting Wire 5 20 2.55/2.1 2.8
OE1042225TRL-M Tapered Tip, Monofilament Cutting Wire 5 25 2.55/2.1 2.8
OE1042230TRL-M Tapered Tip, Monofilament Cutting Wire 5 30 2.55/2.1 2.8



Preloaded Guide Wire Sphincterotome incl. HI-FLEX-Wire 21735450

Length 200 cm; colored ring markers

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1042220TRL-SET01 Tapered Tip 5 20 2.55/2.1 2.8
OE1042225TRL-SET01 Tapered Tip 5 25 2.55/2.1 2.8
OE1042225TRL-M- SET01 Tapered Tip , Monofilament Cutting Wire 5 25 2.55/2.1 2.8
OE1042230TRL-M- SET01 Tapered Tip, Monofilament Cutting Wire 5 30 2.55/2.1 2.8



Sphincterotome “Smart Cut” compatible with Guide Wire .035”

Length 200cm; colored ring markers; partially insulated cutting wire

Catalogue No. Description Tip Length (mm) Cutting Wire Length (mm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE1042220TRLC Tapered Tip 5 20/10 2.55/2.1 2.8
OE1042225TRLC Tapered Tip 5 25/12 2.55/2.1 2.8
OE1042230TRLC Tapered Tip 5 30/15 2.55/2.1 2.8



Needle Knife Sphincterotome compatible with Guide Wire .035”

Colored ring markers

Catalogue No. Needle Projection Needle Stopp at (mm) Length (cm) Outer Sheath Diameter (mm) Min. Accessory Channel (mm)
OE11018N-TRL Pointed Type 6 200 2.55/2.1 2.8
OE11018N4-TRL Pointed Type 4 200 2.55/2.1 2.8
