Stone Extraction Balloons

Description

ENDO-FLEX stone extraction balloons have a distal plastic balloon framed with X-ray markings, a double or triple-lumen plastic tube and three proximal Luer-Lock connectors as access for contrast media, guide wire or 2-way stopcock for inflation

Variant with 1-stage balloon catheter:

  • tube with diameter Fr. 7
  • total length of 260 cm
  • balloon diameter 14 mm

Contains 1 syringe corresponding to the max filling volume

Variant with 3-stage balloon catheter:

  • tube with a diameter of Fr. 7
  • total length from 200 to 250 cm
  • balloon diameters between 9 and 16 mm.

Contains 3 syringes corresponding to the max filling volume

Product Images and Videos

Customer Service
Any Questions about the product? +49 8032 973-0 sales (at) medi-globe.de

More Information

Single Stage Stone Extraction Balloon – Double Lumen, Latex

Incl. syringe for max. air capacity

Catalogue No. Compatible with Guide Wire (inch) Catheter Outer Diameter (French) Balloon Diameter in Deflated Condition (mm) Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
134000 .025 5 1.9 9 1.5 200 2.4
134005 .025 5 1.9 12 2.5 200 2.4
134010 .035 7 2.6 14 2.5 200 2.8
134011 .035 5-7 1.9 14 2.5 200 2.8
134020 .035 7 2.6 18 5.0 200 2.8



Single Stage Stone Extraction Balloon – Double Lumen, Latex-free

Incl. syringe for max. air capacity

Catalogue No. Compatible with Guide Wire (inch) Catheter Outer Diameter (French) Balloon Diameter in Deflated Condition (mm) Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
N135010- 260 .035 7 2.6 14 2.8 260 2.8



Single Stage Stone Extraction Balloon – Triple Lumen, Latex

Incl. syringe for max. air capacity

Catalogue No. Compatible with Guide Wire (inch) Catheter Outer Diameter (French) Balloon Diameter in Deflated Condition (mm) Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
134030 .035 7 2.6 16 5.0 200 2.8
134031 .035 7 2.6 14 4.0 200 2.8
134032 .035 7 2.6 12 2.4 200 2.8
134033 .035 7 2.6 9 2.7 200 2.8

Multi Stage Stone Extraction Balloon – Latex

Compatible with guide wire .035”, incl. 3 syringes for max. air capacity

Catalogue No. Lumen Catheter Outer Diameter (French) Balloon Diameter in Deflated Condition (mm) Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
134010PRO Double 7 2.6 9-13-16 1.5-2.5-5.0 200 2.8
134030PRO Triple 7 2.6 9-13-16 1.5-2.5-5.0 200 2.8



Multi Stage Stone Extraction Balloon – Latex-free

Compatible with guide wire .035”, incl. 3 syringes for max. air capacity

Catalogue No. Lumen Catheter Outer Diameter (French) Balloon Diameter in Deflated Condition (mm) Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
N135010PRO Double 7 2.6 9-13-16 1.5-2.5-5.0 200 2.8
N135030PRO Triple 7 2.6 9-13-16 1.5-2.5-5.0 200 2.8
N135030PRO-250 Triple 7 2.6 9-13-16 1.5-2.5-5.0 250 2.8

Instructions for Use - Stone Extraction Balloons SU latexfree

File size: 0 B
Type:

Instructions for Use - Stone Extraction Balloons SU latex
